HRSG Professional Waste Acid Recycling Boiler With ASME National Board Standard

HRSG Professional Waste Acid Recycling Boiler With ASME National Board Standard

    • HRSG Professional Waste Acid Recycling Boiler With ASME National Board Standard
    • HRSG Professional Waste Acid Recycling Boiler With ASME National Board Standard
    • HRSG Professional Waste Acid Recycling Boiler With ASME National Board Standard
    • HRSG Professional Waste Acid Recycling Boiler With ASME National Board Standard
  • HRSG Professional Waste Acid Recycling Boiler With ASME National Board Standard

    جزئیات محصول:

    Place of Origin: Zhangjiagang,China
    نام تجاری: HD BOILER
    گواهی: ISO9001,ASME,Grade A,SGS,EN
    Model Number: QF 9.5/1050

    پرداخت:

    Minimum Order Quantity: 1Set
    قیمت: Negotiable
    Packaging Details: Seaworthy Packing
    Delivery Time: Negotiation
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 20 Sets / Year
    اکنون تماس بگیرید
    توضیحات محصول جزئیات
    Condition: New Range of Applications: Industrial
    Specification: Customized Surface Treatment: Painted
    Output: Steam Water Circulation: Natural Circulation
    Pressure: Low / Intermediate / High Pressure Port: Shanghai



    Heat Recovery Steam Generators (HRSG)



    Heat Recovery Steam Generators are a type of Waste Heat Recovery unit which uses waste heat (generally from Gas Turbines) to generate steam. Therefore, HRSGs are generally attached to the exhaust of Gas Turbines. They are commonly used in Combined Cycle Power Plants where both Gas and Steam turbines are used to drive generators. Common parts of a heat recovery steam generator include the following:

    • Superheater and desuperheater
    Steam drum, mud drum, drum internals
    Tubes
    Duct Burner for supplemental firing
    Blow down tank
    Economizer
    Firing equipment including duct burner, burner management system, pilot burner
    Bypass stack and exhaust stack, sealing air fan,baffles, piping, valves and controls



    Considerations



    1. The design and construction of HRSG should be such that no detrimental vibration of tubes, piping, casing, transition ductwork and exhaust stack is present under any operating condition.

    2. All components of HRSG system should be capable of being completely drained. Low point drains should be provided for all enclosures, ducts, piping, and coil assemblies. All drain connections provided on coil assemblies should be piped together to provide a single collection point.

    3. Supplementary firing should be adopted as required and can be achieved by duct burners.

    4. If designed and constructed to ASME BPVC, the manufacturer should obtain material certificates for all components, and all required code stamps and certificates .

    5. Superheater elements should be located and supported to prevent vibration, sagging and misalignment

    6. For greater efficiency economizers should generally be furnished as part of an HRSG.



    Configuration



    HRSG Professional Waste Acid Recycling Boiler With ASME National Board Standard



    Technical Parameter



    Cement production line capacity t/d 1000 2500 5000 10000
    Boiler inlet flow Nm3/h Kiln(front) 60000 88000 243000 472000
    Kiln(tail) 76000 170000 328000 612000
    Boiler inlet gas temperature℃ Kiln(front) 370 360 380 390
    Kiln(tail) 360 320~360 330 330
    Rated evaporation t/h Kiln(front) 5.8 7.25 24 50
    Kiln(tail) 7.5 10~15.8 20~24.6 35.5
    Rated steam pressure Mpa Kiln(front) 1.25 1.25 1.25 1.25
    Kiln(tail) 1.25 1.25 1.25 1.25
    Rated steam temperature℃ Kiln(front) 340 330 350 360
    Kiln(tail) 340 300~340 310 310
    Boiler structure Kiln(front) Vertical Vertical Vertical Vertical
    Kiln(tail) Vertical Vertical and Horizontal Vertical and Horizontal Vertical




    Company Introduction



    Established in 1985,Zhangjiagang Hua Dong Boiler Co.,Ltd.(trading as HD Boiler),produces power plant; industrial; waste heat; waste incineration; biomass; organic heat carrier and electric steam boilers. Coupled with a comprehensive range of heating surfaces, HD Boiler brings to the market a unique service including boiler design , fabrication, installation, maintenance and replacement of boiler pressure parts.



    1. Fabrication area of 400,000 square meters

    2. 150 Engineers

    3. 600 Coded welders

    4. 60 Licensed Inspectors(NDT Level-III instructors)

    5. Class-A Licenses for Design and Manufacture Boiler

    6. ISO 9001:2008 Quality System

    7. ASME Certificate of Power Boilers

    8. ASME 'S','U' and NB stamp authorization



    HRSG Professional Waste Acid Recycling Boiler With ASME National Board Standard
